Asus GeForce RTX 4080 ROG STRIX OC 16 GB GDDR6X, 2xHDMI/3xDP, Aura Sync ARGB
ASUS 90YV0IC0-M0NA00
ROG Strix GeForce RTX™ 4080 16GB GDDR6X OC Edition buffed-up design with chart-topping thermal performance.
• NVIDIA Ada Lovelace Streaming Multiprocessors: Up to 2x performance and power efficiency
• 4th Generation Tensor Cores: Up to 2X AI performance
• 3rd Generation RT Cores: Up to 2X ray tracing performance
• Axial-tech fans scaled up for 23% more airflow
• New patented vapor chamber with milled heatspreader for lower GPU temps
• 3.5-slot design: massive fin array optimized for airflow from the three Axial-tech fans
• Diecast shroud, frame, and backplate add rigidity and are vented to further maximize airflow and heat dissipation
• Digital power control with high-current power stages and 15K capacitors to fuel maximum performance
• Auto-Extreme precision automated manufacturing for higher reliability
• GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring
• NVIDIA Ada Lovelace Streaming Multiprocessors: Up to 2x performance and power efficiency
• 4th Generation Tensor Cores: Up to 2X AI performance
• 3rd Generation RT Cores: Up to 2X ray tracing performance
• Axial-tech fans scaled up for 23% more airflow
• New patented vapor chamber with milled heatspreader for lower GPU temps
• 3.5-slot design: massive fin array optimized for airflow from the three Axial-tech fans
• Diecast shroud, frame, and backplate add rigidity and are vented to further maximize airflow and heat dissipation
• Digital power control with high-current power stages and 15K capacitors to fuel maximum performance
• Auto-Extreme precision automated manufacturing for higher reliability
• GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring
Art.nr: 20996
Produkten har utgått
Produktspecifikation
Processor
| Grafikprocessor | GeForce RTX 4080 |
| Grafikprocessor familj | NVIDIA |
| Processorfrekvens boost | 2625 MHz |
| Processorfrekvens (OC mode) | 2655 MHz |
| Stöd för parallellprocessteknik | Stöds inte |
| Max skärmar per grafikkort | 4 |
| CUDA | Ja |
| CUDA-kärnor | 9728 |
| Maximal upplösning | 7680 x 4320 pixlar |
Anslutningar
| Antal DisplayPort | 3 |
| Antal HDMI | 2 |
| HDMI-version | 2.1a |
| DisplayPort-version | 1.4a |
| Gränssnittstyp | PCI Express 4.0 |
Minne
| Minne | 16 GB |
| Minnestyp | GDDR6X |
| Minnesbuss | 256 bit |
| Dataöverföringshastighet | 22,4 Gbit/s |
Design
| Belysning | Ja |
| Belysningsfärg | Blå, Grön, Röd |
| Kylning typ | Aktiv |
| Antal slots | 3,5 |
| Formfaktor | Full-Height/Full-Length (FH/FL) |
| Produktens färg | Svart |
Prestanda
| OpenGL-version | 4.6 |
Vikt & dimension
| Bredd | 357,6 mm |
| Djup | 149,3 mm |
| Höjd | 70,1 mm |
| Vikt | 2,5 kg |
Strömtillförsel
| Lägsta systemströmförsörjning | 750 W |
| Kompletterande strömkontakter | 1x 16-pin |
Fabrikat
| Tillverkare | ASUS |
| SKU | 90YV0IC0-M0NA00 |
| Produktlänk | https://rog.asus.com/graphics-cards/graphics-cards/rog-strix/rog-strix-rtx4080-o16g-gaming-model/ |
