Ubiquiti Utgångsknapp

Dimensions
137 x 88 x 38.1 mm
(5.4 x 3.5 x 1.5")
Weight
180 g (6.3 oz)
Enclosure Material
Polycarbonate
Mount Material
Polycarbonate, SGCC steel
Available Colors
Black, white
Indoor and Outdoor Use
Indoor only
Hardware
Mechanical Life
1,000,000 clicks
Power Method
UniFi Access Hubs
UL 294 Power-limited Class 2 PSU
UL 60950-1/62368-1 LPS/PS2 PSU
Contact Type
(1) Normal open
Contact Rating
30V DC, 2A
UL 294 Level
Destructive attack: Level I
Line security: Level I
Endurance: Level I
Standby power: Level I
UL 294 Statement
Compliance with IEEE 802.3 (at or af) specifications was not verified as part of UL 294.
The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
CAN/ULC-60839-11-1 Grade
Grade assignment: 1
Document number, and issue date and/or revision level
UA-Button, V01
Ambient Operating Temperature
0 to 40° C (32 to 104° F)
Ambient Storage Temperature
-40 to 70° C (-40 to 158° F)
Ambient Operating Humidity
5 to 90% noncondensing
NDAA Compliant
Yes
Certifications
CE, UL 294, CAN/ULC-60839-11-1
